Advanced CPU TW-131
Coin Selector Comparable Coin Acceptor for Vending Machines
Product features:
1. FRONT ENTRY
ELECTRONIC COIN SELECTOR
2. Capable for
accepting all worldwide Coins and Tokens
3. Mechanism—Link with
coin reject bar , Flush Clean from coin jam
4. CPU coin rolling
down speed and timming presetting by directional accept sensors.
5. Invalidate against
unusual stay , Reverse Draw, String Skip, Technical Fishing.
6. Select coin based on
Diameter, Thickness and Metal content.
7. Switch of Normal
Open and Normal Close for signal output of coin validation.
8. 3 ways adjustable
triggering Pulse Duration of Timer Switch.
9. VR tuning and
sensitivity switch of coin acceptance for eliminating slugs and improper coins.
10.Allows to connect
Counter Meter
Specification:
Item: TW-131 Coin Acceptor
Coin Diameter: 22~28 mm
Coin Thickness: 1.7~2.2mm
Voltage: DC 12V ±10%
Current: 65mA ±5%
Accuracy rate of identification: 99%
Temperature: -15°C~+75°C
Atmospheric pressure: 86Kpa—106Kpa
Signal Output: Pulse
Pluse Witdth: 20ms/40ms/100ms
Speed: ≤0.6s
Application Area:
Our coin acceptor
widely used in coin kiosk, coin mechanism, coin device, car washing machine,
TV, massage chair, cloth dryer, cyber coffee, Laundromat, laundry,computer
,amusement machine , arcade machine etc.
